FeatureAccessible seating

Accessible seating2010 ADA StandardsChecked October 6, 2026

The ADA Standards require 5 percent of patio seats and standing spaces to be accessible, rounded up

Under the 2010 ADA Standards, a 120-seat restaurant patio needs at least 6 dining spaces that meet section 902, and a 330-space terrace needs 17.

Minimum accessible spaces, 120-seat patio

Share required
5 percent
Seats and standing spaces at dining surfaces, 226.1
Fractions
Round up
6.6 becomes 7, under 104.2
Café patio, 40 seats
2
Accessible spaces required
Terrace, 330 spaces
17
300 seats and 30 standing at a bar
Sheet AOn a 120-seat patio, the 6 accessible positions can be spread across all three sections
ASHADED SECTIONSHADE STRUCTURE ABOVEBBY THE RAILINGCNEAR THE BARBAR COUNTERSEAT AT A 29-INCH TABLESEAT AT A 42-INCH BAR-HEIGHT TABLEACCESSIBLE POSITION120 SEATS COUNTED. 5 PERCENT IS 6. TWO ACCESSIBLE POSITIONS IN EACH SECTION. ASHADEBRAILINGCBARBAR COUNTERSEAT AT A 29-INCH TABLESEAT AT A 42-INCH BAR TABLEACCESSIBLE POSITION120 SEATS COUNTED. 6 ACCESSIBLE, 2 PER SECTION.

Example plan of a 120-seat patio by table type: 60 seats at 15 four-seat tables, 20 at 10 two-seat tables and 40 at 10 bar-height tables. Not to scale; round numbers, not a real property. Rules from the U.S. Access Board's text of the 2010 ADA Standards, sections 226.1, 226.2 and 902, checked October 6, 2026.

TitleAccessible dining spaces on a patio
Dwg no.evergreen-counting-accessible-seats-on-a-restaurant-patio
ScaleNTS
Rev2010 Standards
Sheet1 of 1
DrawnCommercial Outdoor Furniture
UnitsSpaces, inches

Section 226.1 of the 2010 ADA Standards for Accessible Design requires that at least 5 percent of the seating spaces and standing spaces at dining surfaces meet the technical rules in section 902. Section 104.2 tells you to round any fraction up to the next whole number.

A café patio with 40 seats needs at least 2 accessible dining spaces, a 120-seat restaurant patio needs 6, and a 300-seat hotel pool terrace needs 15. The count covers every seat and standing space at a dining surface, including bar-height tables and drink rails, so adding 30 standing spaces at a bar on that terrace raises the minimum to 17. The rules quoted here are from the U.S. Access Board's text of the standards, checked October 6, 2026.

The worked examples below use round numbers and describe no real property. The ADA guide covers the same sections in more detail, along with benches and federal picnic areas.

226.1Every seat and standing space counts, and 16.5 rounds up to 17

Section 226.1 counts seating spaces and standing spaces. Where dining surfaces are provided for the consumption of food or drink, "at least 5 percent of the seating spaces and standing spaces at the dining surfaces shall comply with 902." The Access Board's advisory note to section 902 says dining surfaces include bars, tables, lunch counters and booths.

The Department of Justice explains the choice in its guidance on the 2010 standards. Commenters asked it to go back to counting fixed tables, as the 1991 standards did. The Department kept the count of seats and standing spaces because tables vary in size, and it says counting tables could limit the choices open to people with disabilities.

Section 104.2 sets the rounding. When a percentage leaves a fraction, the standards call for the next greater whole number. A count of 6.6 becomes 7, and a count of 16.5 becomes 17.

Sheet BAdding 30 standing spaces at a bar takes the terrace from 15 required spaces to 17
06012018024030036005101520SEATS AND STANDING SPACES COUNTEDACCESSIBLE SPACES REQUIREDEXACT 5 PERCENTSTEPS: ROUNDED UP UNDER 104.216.5 ROUNDS TO 1712345NOTES1CAFÉ PATIO40 SPACES: 22RESTAURANT PATIO120 SPACES: 63WITH A DRINK RAIL132 SPACES: 6.6, SO 74HOTEL POOL TERRACE300 SPACES: 155WITH A BAR330 SPACES: 16.5, SO 17 012024036005101520SEATS AND STANDING SPACES COUNTEDACCESSIBLE SPACES REQUIRED12345NOTES1CAFÉ PATIO40 SPACES: 22RESTAURANT PATIO120 SPACES: 63WITH A DRINK RAIL132 SPACES: 6.6, SO 74HOTEL POOL TERRACE300 SPACES: 155WITH A BAR330 SPACES: 16.5, SO 17

Minimum accessible dining spaces by the number of seats and standing spaces counted: 5 percent under section 226.1, rounded up to the next whole number under section 104.2. The five patios are round-number examples, not real properties. Standing-space figures are assumptions for illustration. Source: 2010 ADA Standards, U.S. Access Board, checked October 6, 2026.

Standing spaces at a drink rail or a standing-height bar raise the total. Section 226.1 does not say how much rail length makes one standing space, so the person who designs the patio has to settle on a number per foot of rail and use it for the count. Write that figure into the seating plan so the count can be checked later.

902The 6 accessible spaces have to come from the 80 seats at 29-inch tables

A space counts toward the 5 percent only at a surface that meets section 902. The top of the table has to be 28 to 34 inches above the ground. The position needs a clear ground space of 30 by 48 inches for a forward approach, with knee and toe clearance under the table. Section 305.4 lets the clear space include the knee and toe clearance, so part of the 48 inches can sit under the table.

Sheet COne accessible position needs 30 by 48 inches of clear ground and at least 17 inches of toe space under the table
PLANTABLE TOPCLEAR GROUNDSPACE30 IN48 IN17 MINTOE CLEARANCEUNDER THE TABLESECTIONTOP 28 TO 34 IN17 MIN11 MIN8 MIN9 IN27 INTOEKNEE PLANTABLE TOPCLEAR GROUNDSPACE30 IN48 IN17 MINTOE CLEARANCEUNDER THE TABLESECTIONTOP 28 TO 34 IN17 MIN11 MIN8 MIN9 IN27 INTOEKNEE

Minimum dimensions in inches for one forward-approach dining position, from sections 902.3, 305.3 and 306. The shaded profile in the section is the minimum knee and toe clearance; the plan draws the clear ground space with its toe clearance under the table, as section 305.4 allows. Table size and legs are not to scale. Source: 2010 ADA Standards, U.S. Access Board, checked October 6, 2026.

That rules out any bar-height table with a top above 34 inches. Seats at those tables still count in the total, so the accessible spaces have to come from the lower tables.

Sheet DThe 40 seats at 42-inch bar tables count toward the 120, and none of them can be one of the 6
TOP 28 TO 34 IN29 IN42 INDINING TABLEBAR-HEIGHT TABLECOUNTS, CAN BE ACCESSIBLECOUNTS, CANNOT BE ACCESSIBLESEATS BY TABLE TYPE, ONE SCALEFOUR-SEAT DINING, 15 TABLES60TWO-SEAT DINING, 10 TABLES20BAR-HEIGHT, 10 TABLES40ALL 120 SEATS80 AT 29 IN40 AT 42 IN6 REQUIRED, ALL FROM THE 80 TOP 28 TO 34 IN29 IN42 INDINING TABLEBAR-HEIGHT TABLECOUNTS, CAN BE ACCESSIBLECOUNTS, CANNOT BEACCESSIBLESEATS BY TABLE TYPE, ONE SCALEFOUR-SEAT DINING, 15 TABLES60TWO-SEAT DINING, 10 TABLES20BAR-HEIGHT, 10 TABLES40ALL 120 SEATS80 AT 29 IN40 AT 42 IN6 REQUIRED, ALL FROM THE 80

Example 120-seat patio by table type, in seats, with table-top heights in inches against the 28 to 34 inch range in section 902.3. Round numbers, not a real property. Source: 2010 ADA Standards, U.S. Access Board, checked October 6, 2026.

In this example, all 120 seats go into the count, and the result is 6. The 40 seats at bar-height tables cannot supply any of the 6. They have to be at the 25 dining tables, and only at tables whose bases leave the clearance below.

Section 226.2 adds dispersion: the accessible dining surfaces must be spread throughout the space or facility that has dining surfaces. On a patio with a shaded section, a section by the railing and a section near the bar, the seating plan can place accessible positions in each of the three, as Sheet A at the top of this page does.

206.2.5The route to every dining area is at least 36 inches wide

Section 206.2.5 requires an accessible route to all dining areas in restaurants and cafeterias, and names raised, sunken and outdoor dining areas among them. The Access Board's guide says this applies to newly built restaurants and cafeterias. In alterations, an exception says the route need not reach all parts of an existing outdoor dining area where the same services and decor are provided in an accessible space open to the public. The standards' examples of the same decor include seating at or near windows and railings with views.

Sheet EThe route is at least 36 inches wide, with a running slope no steeper than 1:20
RUNNING SLOPE 1:20 MAXCROSS SLOPE1:48 MAX36 MINACCESSIBLE ROUTE TO EVERY DINING AREA, PLANSURFACE STABLE, FIRM AND SLIP RESISTANT (302.1)GROUND UNDER EACH ACCESSIBLE TABLE POSITION: 1:48 MAX SLOPE RUNNING SLOPE 1:20 MAXCROSS SLOPE 1:48 MAX36 MINACCESSIBLE ROUTE TO EVERY DINING AREA, PLANSURFACE STABLE, FIRM AND SLIP RESISTANT (302.1)GROUND AT EACH TABLE POSITION: 1:48 MAX

Minimum width and maximum slopes of an accessible route and of the ground at each accessible table position, from sections 302.1, 403 and 902 of the 2010 ADA Standards. Not to scale. Source: U.S. Access Board, Guide to the ADA Accessibility Standards, Chapter 4, checked October 6, 2026.

The walking surface of the route must be at least 36 inches wide, with a running slope no steeper than 1:20 and a cross slope no steeper than 1:48. The ground under the clear space at each accessible table position may slope no more than 1:48. Section 302.1 requires floor and ground surfaces to be stable, firm and slip resistant, which matters on a patio of gravel, pavers or decking.

NotesWhat to do with this before ordering

  1. Count every seat and standing space on the seating plan, apply 5 percent and round up. Then count only the positions at tables 28 to 34 inches high with a clear base, and check that the second number is at least as large as the first.

  2. Ask the maker for a dimensioned drawing of each table base. Check the clear width between legs or under the apron against the 30-inch knee and toe width, and the depth against the 17-inch toe and 11-inch knee minimums. A pedestal foot or a center umbrella pole can cut into both.

  3. Mark the accessible positions on the plan, spread across the patio, and keep the plan with the furniture order.

Movable furniture shifts during service. The Department of Justice regulation for businesses open to the public, 28 CFR 36.211, requires a public accommodation to maintain the features that must be accessible in operable working condition, and allows isolated or temporary interruptions for maintenance or repairs. Staff who reset the patio each day need the plan too.

General notesCaveats

These are the federal 2010 ADA Standards. State and local building codes can set more. The architect of record, the local building official or an accessibility consultant should confirm what applies to a given patio.

The Department of Justice guidance says the 2010 standards set requirements for fixed or built-in elements in new or altered facilities. Once construction is finished, the Department says, the facility falls under the regulations' operational requirements, and it may use the standards as a guide for equipment and furnishings. Whether movable patio tables and chairs are treated as fixed elements is a question for the project's architect or counsel. Naming section 902 in the purchase specification gives the dealer a requirement it can measure a table against.

The standing-space figures in the examples are assumptions for illustration.

SchedulesFive example patios, three table types and 9 dimensions

Minimum accessible dining spaces, example patios. Section 226.1, rounded up under 104.2.
Patio (example)SeatsStandingCounted5 percentRequiredRequired, as a bar
Café patio4004022
Restaurant patio120012066
Restaurant patio with a drink rail120121326.67
Hotel pool terrace30003001515
Hotel pool terrace with a bar3003033016.517
Example 120-seat patio by table type.
Table type (example)Top, inTablesSeatsCan count toward the 5 percent
Four-seat dining table291560Yes, where the base leaves knee and toe clearance
Two-seat dining table291020Yes, where the base leaves knee and toe clearance
Bar-height table421040No, the top is above 34 inches
One accessible dining position and the route to it, in inches.
RequirementMinMaxSection
Height of the table top above the ground2834902.3
Clear ground space width30 305.3
Clear ground space length48 305.3
Knee clearance width30 306
Knee clearance depth at 9 inches above the ground1125306
Knee clearance depth at 27 inches above the ground8 306
Toe clearance width30 306
Toe clearance depth under the table1725306
Accessible route clear width36 403

Sources: 2010 ADA Standards, U.S. Access Board, checked October 6, 2026. Download the data: counts (CSV), table types (CSV), dimensions (CSV).
